Hi All
Managed to get back to the sim.
I tried script V6.4P and found the following issues with it. This is related to the MIP part of the script and were causing me problems.
Problem 1:
Var 2368, name bBELOW_GS, static, Link IOCARD_SW, Device 31, Input 33
Var 2377, name bBELOW_GS_1, static, Link IOCARD_SW, Device 31, Input 13
The Captain's and F.O's 'Below GS' are not INPUT's, as indicated in the above two lines. They are OUTPUT's, and their numbers are 33 and 52 respectively. INPUT's 33 & 13 are already assigned to other variables, as shown below. These duplicate INPUT's are conflicting, so the above two lines need to be deleted from the script.
Var 0512, name sGRDPROXFLAP, Link IOCARD_SW, Device 31, Input 33
Var 0465, name sFO_PFD, Link IOCARD_SW, Device 31, Input 13
The script has two OUTPUT's for Below GS, also shown below, .[/i]
Var 1298, name aBELOWGS_0, static, Link IOCARD_OUT, Device 31, Output 33
Var 1299, name aBELOWGS_1, static, Link IOCARD_OUT, Device 31, Output 52
Problem 2:
The Landing Gear INPUT numbers in the two lines below are incorrect. They should be numbers 69 and 70.
Var 0489, name bGEAR_LEVER_UP, Link IOCARD_SW, Device 31, Input 59
Var 0490, name bGEAR_LEVER_DN, Link IOCARD_SW, Device 31, Input 60
Again, these duplicated INPUT's are causing conflicts. The correct variables with these numbers are below.
Var 0475, name sAUTOBRAKE_MAX, Link IOCARD_SW, Device 31, Input 59
Var 2560, name bENG_BUT_SEL, static, Link IOCARD_SW, Device 31, Input 60, Type P
Problem 3:
I've noticed that the Oi4FS software is assigning TWO Mastercards to the MIP's USB Expansion card. This appears to be because of the following line entry in the Oi4FS.ini file:
MIP,IDX31m2
Regardless of the MIP being OC's Dual or Single seat, it has only ONE Mastercard. Having TWO cards assigned is causing spiking problems in the SIOC software, because it's looking for a second Mastercard that isn't there. I've changed my line entry to:
MIP,IDX31m1
It now assigns only ONE Mastercard and SIOC is running OK for the MIP USB Expansion.
I've based the above number findings on the original Opencockpits Dual MIP script. After deleting line variables 2368 & 2377, correcting line variables 0489 & 0490, and changing IDX31 to m1 the MIP is now working correctly.
Regards.
Ian
